20
2) Fix the support lever into the holder body, make sure the support lever is located in position (fig. 55 & 56).
3) To change the height of rear wheel, unscrew the height adjustment knob #26. Pull out the wheel axle
sideward and insert it into another hole relating to the desired height. The height in millimeters is
embossed in the bracket #26. Reassemble (fig. 57 & 58).
Figure 54 Figure 55 Figure 56
Figure 57 Figure 58
Remember the cutting height on the front wheel should be the same as on the rear wheels!
8. MAINTENANCE INSTRUCTIONS
Good maintenance is essential for safe, economical and trouble-free operation. It is also necessary to maintain
the low emission level of the engine.
Remember that an authorized servicing dealer knows your engine best and is fully equipped to maintain and
repair it.
SPARK PLUG
Use only original manufacturer replacement spark plugs. For best results, replace the spark plug every 100
hours of use.
Recommended spark plug ► Torch F7RTC.
WARNING:
Incorrect spark plugs can cause engine damage.
For good performance, the spark plug must be properly gapped and free of deposits.
1. Disconnect the cap (part 10) from the spark plug, and remove any dirt from the spark plug area.
2. Use the spark plug wrench (accessory part A) to remove the spark plug.
3. Inspect the spark plug. Replace it damaged or corroded, if the sealing washer is in poor condition or if the
electrode is worn.
