Garland G Series Technical Reference Manual

Part # GCTRM Rev 3 (12/10/09)Page 14
Model Width Description
M,MS,MST24B(E) 24 24” wide char-broiler
M,MS,MST34B(E) 34 34” wide char-broiler
M35 17 Deep fat fryer
M70 24 Deep fat fryer
Minimum Supply Pressure: Manifold Operating Pressure:
NAT – 7” WC NAT – 6” WC
PRO – 11” WC PRO 10” WC
Garland 40 Series Heavy Duty
Sux Denitions
R Standard oven base
RC Convection oven base
S Storage base
SD Storage base with doors
T Modular top/Table top
FT Front open burner, rear hot top
G Griddle
GTH Thermostatically controlled griddle
Model Width Description
42-40R 34” 17” Valve controlled griddle on the left and 2 open top burners w/standard oven
42-40R-6 34” 17” even heat hot top on the left and 2 open top burners w/standard oven
42-40R-5 34” 17” spectro-heat plate and 2 open burners
43-40R 34” 6 open top burners with standard oven
43-40FTR 34” 3 open burners front and 3 hot tops rear with standard oven
43-40R-34G 34” 34” Valve controlled griddle with standard oven
44-40R 34” 4 open top burners with standard oven
44-40FTR 34” 2 open top burners front and 2 hot tops rear with standard oven
45-40R 34” Two 17” spectro-heat plate sections with standard oven
46-40R 34” Two 17” even heat plate sections with standard oven
47-49R 34” 34” valve controlled griddle with standard oven - US built only
48-49R 34” 34” thermostatically controlled griddle with standard oven - US built only
40-4S 17” 2 open top burners with storage base
40-5S 17” 17” spectro-heat plate with storage base
40-6S 17” 17” even heat plate with storage base
40-7S 17” 17” valve controlled griddle with storage base
40-8S 17” 17” thermostatically controlled griddle with storage base
2-40 34” Double stacked standard oven
Oven Burner 40,000 BTU/Hr (Standard and RC ovens)
Open Burner 14,000 BTU/Hr each 12” section (ex. 43-40R)
14500 BTU/Hr for units built in Mississauga
Open Burner 20,000 BTU/Hr each 17” section (ex. 44-40R)
Spectro-heat burner 15,000 BTU/Hr each burner, 45,000 BTU/Hr per 17” section
Even Heat Hot Top 30,000 BTU/Hr each burner US built - 27,000 built in Mississauga
Griddle Burner 30,000 BTU/Hr each burner (valve and thermostatically controlled griddles
27,000 BTU/Hr each burner for units built in Mississsauga
Minimum Supply
Pressure:
Manifold Operating
Pressure:
NAT – 7” WC NAT – 6” WC
PRO – 11” WC PRO 10” WC
