LMM for the Kodiak 100 Page 2-15
190-02102-00 Rev.4
Table 2-3. GMA 1347 Control Functions
1 COM1 MIC Selects the #1 COM for transmitting. The COM1 receiver is
simultaneously selected when this key is pressed, allowing
received audio from the COM1 receiver to be heard. COM2
receiver audio can be added by pressing the COM2 Key.
2 COM1 When selected, the #1 COM receiver audio can be heard.
3 COM2 MIC Selects the #2 COM for transmitting. The COM2 receiver is
simultaneously selected when this key is pressed, allowing
received audio from the COM2 receiver to be heard. COM2
can be deselected by pressing the COM2 Key, or COM1 can
be added by pressing the COM1 Key.
4 COM2 When selected, the #2 COM receiver audio can be heard.
5 COM 3 MIC Not used.
6 COM 3 Not used.
7 COM 1/2 Not used.
8 TEL Not used.
9 PA Selects the passenger address system. The selected COM
transmitter is deselected when the PA Key is pressed.
10 SPKR Selects and deselects the cabin speaker. COM and NAV
receiver audio can be heard on the speaker.
11 MKR/MUTE Mutes the currently received marker beacon receiver audio.
Unmutes when new marker beacon audio is received. Also,
stops play of the clearance recorder.
12 HI SENS Press to increase marker beacon receiver sensitivity. Press
again to return to normal.
13 DME Not used.
14 NAV 1 When selected, audio from the #1 NAV receiver can be heard.
15 ADF Not used.
16 NAV 2 When selected, audio from the #2 NAV receiver can be heard.
17 AUX Not used.
18 MAN SQ Press to enable manual squelch for the intercom. When
active, press the PILOT Knob to illuminate 'SQ'. Turn the
PILOT/PASS Knobs to adjust squelch.
