Yamaha Engine Gauges
Select A/V, Gauges, Controls > YAMAHA to view the Yamaha engine gauges. This screen varies based on the
engine network and throttle controller.
Data fields
Hold to replace the data.
Current time
Hold to view trip data.
Select to toggle the autopilot bar on and off (Helm Master
®
EX).
Select to set the joystick button for Set Point functions (Helm Master).
Tank level information
Hold a tank to view detailed tank level sensor information.
Status icons
GPS signal strength (Helm Master)
Select to set the Fish Point settings (Helm Master/Helm Master EX).
Select to set the trolling speed (Helm Master/Helm Master EX/Mechanical RC/Digital Electronic RC
(6X6/6X7)).
Data fields
Hold to replace the data.
Shift position
Tachometer and trim angle
Hold to change the background.
Engine information
Hold to replace the data and change the gauge appearance.
112 Gauges and Graphs
