6 CONTROLS
14
6.1 Hand brake lever
F02966-10
Hand brake lever
1
is fitted on the right side of the handlebar.
The hand brake lever is used to activate the front brake.
6.2 Throttle grip
F02966-11
Throttle grip
1
is fitted on the right side of the handlebar.
6.3 Stop button
F02967-10
The stop button
1
is fitted on the left side of the handlebar.
Possible states
• The stop button is in the basic position – In this position, the
ignition circuit is closed and the engine can be started.
• Stop button pressed – In this position, the ignition circuit is inter-
rupted, a running engine stops, and a non-running engine will not
start.
6.4 Opening the fuel tank filler cap
Danger
Fire hazard Fuel is highly flammable.
The fuel in the fuel tank expands when warm and can escape if overfilled.
– Do not fuel the vehicle in the vicinity of open flames or lit cigarettes.
– Switch off the engine for refueling.
– Make sure that no fuel is spilled; particularly not on hot parts of the vehicle.
–
If any fuel is spilled, wipe it off immediately.
– Observe the specifications for refueling.
