WHEELS, TIRES 13
75
13.1 Removing the front wheel
Preparatory work
–
Raise the motorcycle with a lift stand. ( p. 37)
F03005-11
Main work
–
Loosen screw
1
by several rotations.
–
Loosen screws
2
.
–
Press on screw
1
to push the wheel spindle out of the axle clamp.
–
Remove screw
1
.
F03006-10
Warning
Danger of accidents Damaged brake discs reduce the
braking effect.
– Always lay the wheel down in such a way that the brake
disc is not damaged.
– Hold front wheel and remove wheel spindle. Take the front wheel
out of the fork.
Info
Do not actuate the hand brake lever when the front wheel is
removed.
F03044-10
–
Remove spacers
3
.
13.2 Installing the front wheel
Warning
Danger of accidents Oil or grease on the brake discs reduces the braking effect.
– Always keep the brake discs free of oil and grease.
– Clean the brake discs with brake cleaner when necessary.
