Gate Titan User Guide

21
WWW.GATEE.EU
USER GUIDE
22
23
21
20
Close the gearbox. Tighten two screws on
the top part of the gearbox case.
Prepare selector plate. If selector plate
doesn’t have copper connector, you need
to modify it.
The black surface does not reflect light, so
sensors cannot work properly.
In order to modify the black plate, use the
sticker from the installation kit. At first, try
to use the 'middle' sticker.
ATTENTION! If the selector plate has
copper connector, do not make any
modifications.
Black plate after modification.
The sticker location is very important. It
should be as close to the left side as
possible.

Gate Titan Specifications

General

MOSFET	Yes
Battery protection	Yes
Trigger sensitivity adjustment	Yes
Pre-cocking	Yes
ROF control	Yes
Active brake	Yes
Diagnostic system	Yes
Programmable	Yes
Cycle Detection	Yes
Compatibility	V2 Gearbox
Low current consumption in sleep mode	0.2mA
Connectivity	USB-Link, Blu-Link
Fire Modes	Semi, Burst
Bluetooth support	Yes
