Gates MOBILE CRIMP 4-20 - Page 2

2
Shop Air Pump
Prod. No.: 7481-0002, Part No.: 77820
Weight: 10 lbs.
1/4 H.P. 12 Volt DC Pump
Prod. No.: 7481-0037, Part No.: 77439
Weight: 20.5 lbs.
1/2 H.P. 115 Volt AC Pump
Prod. No.: 7481-0034, Part No.:77441
Weight: 32 lbs.
Hand Pump
Prod. No.: 7481-0006, Part No.: 77821
Weight: 25.6 lbs.
1-1/2 H.P. 115 Volt AC Pump
Prod. No. 7481-0035
Weight: 108 lbs.
Carefully read and understand all the following warnings before operating this crimper.
WARNING!
An incorrect hose assembly can rupture or blow apart in use, resulting in serious injury, death, or
property damage. REMEMBER: Others depend on you to make correct assemblies.
FOR SAFETY’S SAKE USE THIS MACHINE ONLY IF YOU:
1. Receive hands-on TRAINING with this Gates crimper and assemblies.
2. Follow current GATES OPERATING MANUAL and CRIMP DATA for the MoblieCrimp
®
4-20.
3. Use only NEW (UNUSED) GATES hose and ttings.
4. Wear SAFETY GLASSES.
5. KEEP HANDS CLEAR of moving parts.
PUMP SPECIFICATIONS
All pumps maximum rated working pressure: 10,000 psi
DIGITAL DIAL CONTROL
Prod. No.: 7480-0051, Part No.: 77421
Dimensions: 12 1/4" wide x 6 1/4" deep x 19 1/2" high
Weight: 57 lbs. (with stand)
