PY800AC/PY1400AC SLIDING GATE OPERATOR
2
Duty cycle S2, 15 minutes S2, 15 minutes
extra remote control 20 20
Environmental
temperature
-20 ° C~+50 ° C -20 ° C~+50 ° C
Gate Move speed 12m/min 14m/min 12m/min 14m/min
4.
4.
4.
4. Mechanical
Mechanical
Mechanical
Mechanical Installation
Installation
Installation
Installation
The PY800AC/PY1400AC will handle gate weighting up to 800kg/1400 kg
and up to 14m/20m if the proper installation procedures have been
followed.
The PY800AC/PY1400AC gate operator operates by forcing a drive rack
by a drive gear. The entire configuration is shown in the diagram below.
The gate operator must be installed on the inside of the gate.
Fig.1
Gate preparation
Be sure the gate is properly installed and slides smoothly before installing
the PY800AC/PY1400AC sliding gate operator. The gate must be plumb,
level, and move freely.
Conduit
