ETX SOFT ROLL-UP BED COVER
GATOR ETX SOFT ROLL UP
TONNEAU COVERS, 2303 SE 17TH ST
, SUITE 102, OCALA, FL 34471
6
12 * Hook Strip
13 1703332 Hitch Pin
14 1706362 Clamp Assembly (6)
15 *
16 *
Side Rail, Passenger’s Side
Side Rail, Driver’s Side
17 1114773 Flat Spring
18 1704213 Latch Assembled
19 1703455 Cap Screw
20 1705336 Header Stop
21 1705629 Self Drill Screw
22 1705405 Rear Header End Plug RH
23 1705404 Rear Header End Plug LH
24 *
Rear Header
25 1706421 Side Rail End Plug Assy LH
26 1706422 Side Rail End Plug Assy RH
27 1701580 Hex Nut Full Nylon Lock
28 * Extruded Header Seal
29 1706424 Four Corner Weather Seal Pack
* Please specify length or make and model of vehicle
1 * Replacement Cover
2 * Front Header
3 1705310 Front Header End Plug RH
4 1705311 Front Header End Plug LH
5 * Retainer Strap
6 1115745 Plastic Washer
7 1703455 Square Head Cap Screw
8 * Bow Assembly
9 1705192 Retainer Loop
10 1705318 Tension Adjustment Block
11 1705364 Header Insert Retainer Clip
REPLACEMENT PARTS
