GE Security Concord 4 Installation Manual

Concord 4
Installation Manual
14
(during normal standby condition) using a 4.5 or 5.0 Ah battery, or 190 mA (during normal standby condition)
using a 7.0 Ah battery.
The total system wire length allowed can vary depending on devices powered by the panel, the wire length
between devices and the panel, and the combined wire length of all devices.
Table 4 describes the maximum wire length allowed between compatible devices and the panel, and the
minimum and maximum current draw of each device.
Table 4. Wire length requirements
Device
Max. wire length to
panel
Standby mA
draw
Alarm mA draw
SuperBus 2000 2x16 LCD alphanumeric touchpad 22 ga:300 ft.
18 ga.:750 ft.
15 mA 90 mA
SuperBus 2000 ATP 1000 alphanumeric touchpad 22 ga.:300 ft.
18 ga.:750 ft.
12 mA 110 mA
SuperBus 2000 ATP 2100 alphanumeric touchpad 22 ga.:300 ft.
18 ga.:750 ft.
30 mA 165 mA
SuperBus 2000 ATP 2600 alphanumeric touchpad 22 ga.:300 ft.
18 ga.:750 ft.
30 mA 165 mA
SuperBus 2000 GTS 50 22 ga.:100 ft.
18 ga.:250 ft.
270 mA 300 mA
SuperBus 2000 fixed display touchpad 22 ga.:300 ft.
18 ga.:700 ft.
11 mA 65 mA
SuperBus 2000 FTP 1000 fixed display touchpad 22 ga.:300 ft.
18 ga.:700 ft.
12 mA 75 mA
SuperBus 2000 RF transceiver 22 ga.:1,000 ft.
18 ga.:2,500 ft.
45 mA 55 mA
SuperBus 2000 RF receiver* 22 ga.:1,100 ft.
18 ga.:2,800 ft.
35 mA 35 mA
SuperBus 2000 phone interface/voice module 22 ga.:40 ft.
18 ga.:120 ft.
25 mA 600 mA
SuperBus 2000 voice-only module 22 ga.:40 ft.
18 ga.:120 ft.
20 mA 300 mA (jumper)
600 mA (no jumper)
SuperBus 2000 2 amp power supply No load No load
4 input/2 output SnapCard N/A 20 mA 185 mA*
8Z hardwired zone expander SnapCard N/A 38 mA 230 mA*
4 output SnapCard N/A 1 mA 130 mA*
SuperBus 2000 8Z input module 22 ga.:1,800 ft.
18 ga.:4,000 ft.
18 mA 35 mA
SuperBus 2000 4-relay output module 22 ga.:350 ft.
18 ga.:900 ft.
12 mA 180 mA
