INSTALLATION INSTRUCTIONS
Installation Instructions
REVERSING THE DOOR SWING (Cont.)
5
REVERSING THE DOOR HANDLES
5.1. Remove handle screws from the top of fresh
food door. Remove handle screws from the
bottomoffreezerdoor.
5.2. Remove door handle on fresh food door by
sliding the handle up off of the fastener (Plastic
Handle) or plastic bushing (Stainless Steel
Handle).Removedoorhandleonfreezerdoor
by sliding the handle down off of the fastener
(Plastic Handle) or plastic bushing (Stainless
Steel Handle).
5.3. Change places between the handle fastener or
plastic bushing and plug button on door front.
5.4. Move the plug buttons on top and front of the
door to fill the now vacant holes.
5.5. Transfer the door stop on the bottom of the
door.
5.6. Attach handle to fresh food door by sliding
handle down onto fastener (Plastic Handle) or
plastic bushing (Stainless Steel handle) and
with screws at top of handle.
5.7.Attachhandletofreezerdoorbyslidinghandle
up onto fastener (Plastic Handle) or plastic
bushing (Stainless Steel handle) and with
screws at bottom of handle.
5.8.Attachbadgeonfreezerdooroppositethe
handle.
Door
Stop
