GE 898693 - PARTS

44
PARTS
max
self
clean
auto
shutoff
auto o
cotton-linen
wool
silk
synthetics
o
1
7
10
2
3
5
4
6
8 9
11
13
14
15
16
17
18192021
12
1. Spray nozzle
2. Fill inlet cover
3. Fill inlet
4. Temp. button
5. Function control
: dry ironing
: steam output
: steam ironing
6. Spray button
7. Steam burst button
8. Handle
9. Swivel cord guard
10. Heel
11. Power cord with power plug
12. Temperature display panel
13. auto o indicator
14. cotton-linen indicator
15. wool indicator
16. silk indicator
17. synthetics indicator
18. o indicator
19. self clean button
20. Water tank
21. Soleplate with steam nozzles
