8.1 Component volumes
Module volumes
The table below lists the internal volumes of the modules in ÄKTA pilot 600 system.
Internal volume (mL)Module
0.7External air sensor
4.3Inlet valve
7.1Pump (two pump heads)
4.9Pump rinse system
3.9Flow restrictor
3.9Air trap valve
73.7Air trap
3.4Mixer valve
5.4Mixer chamber
15.0Column valve
0.4Conductivity monitor
0.2UV monitor (2.0 mm flow cell)
0.5UV monitor (5.0 mm flow cell)
0.8pH monitor
3.6Outlet valve 1
4.0Outlet valves 2 to 5
