CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-215
2
F629
ENUMERATION: SCADA PROTOCOL
0 = DNP 3.0, 1 = IEC 60870-5-104, 2 = IEC 60870-5-103
F630
ENUMERATION: IEC 103 ASDU TYPE
0 = 3, 1 = 9
F631
ENUMERATION: VIRTUAL INPUTS FOR IEC 103
F632
ENUMERATION: CID FILE STATUS
0 = None, 1 = Received, 2 = Rejected, 3 = Accepted, 4 = Private
Section Error
F633
ENUMERATION: IEC 61850 CONTROL MODEL
F634
ENUMERATION: IEC 61850 CONTROL MODEL - NORMAL
SECURITY ONLY
0 = Status-only, 1 = Direct-with-normal-security, 2 = SBO-with-
normal-security
F635
ENUMERATION: RS232 BAUD RATE
0 = 19200, 1 = 115200
F636
TEXT20: 20 CHARACTER ASCII TEXT DISPLAYED TRUNCATED
TO 12 CHARACTERS
F637
TEXT20: 20 CHARACTER ASCII TEXT DISPLAYED TRUNCATED
TO 6 CHARACTERS
F639
ENUMERATION: SCADA EVENT TIME BASE (DNP/104/103)
0 = UTC, 1 = LOCAL
F647
ENUMERATION: GRAPHICAL FRONT PANEL PAGE
Enumeration Item
0OFF
1 Virtual Input 1
2 Virtual Input 2
3 Virtual Input 3
↓↓
64 Virtual Input 64
Enumeration Item
0 Status-only
1 Direct-with-normal-security
2 SBO-with-normal-security
3 Direct-with-enhanced-security
4 SBO-with-enhanced-security
Enumeration Item
0 Product Information
1 Single-line Diagram (SLD) 1
2SLD2
3SLD3
4SLD4
5SLD5
6 Annunciator
7 Annunciator 1
8 Annunciator 2
9 Annunciator 3
10 Annunciator 4
11 Annunciator 5
12 Annunciator 6
13 Annunciator 7
14 Annunciator 8
15 Phasors 1
16 Phasors 2
17 Phasors 3
18 Phasors 4
19 Phasors 5
20 Phasors 6
21 Tabular 1
22 Tabular 2
23 Tabular 3
24 Tabular 4
25 Tabular 5
26 Event Records
27 Targets
