3-194 UR FAMILY – COMMUNICATIONS GUIDE
MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION
3
3.5.6.8 Digital elements (DigEl)
This element is instantiated all UR products (B30, B90, C30, C60, C70, D30, D60, F35, F60, G30, G60, L30, L60, L90, M60, N60,
T35, T60).
Table 3-211: Digital element data objects
3.5.6.9 FlexElement element (FlxEl)
This element is instantiated in the following products: B30, C30, C60, C70, D30, D60, F35, F60, G30, G60, L30, L60, L90, M60,
N60, T35, T60.
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef2 ORG COUNTER # DOWN setting. R
setSrcRef ObjectReference SP COUNTER # DOWN setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef3 ORG CNT# SET TO PRESET setting. R
setSrcRef ObjectReference SP CNT# SET TO PRESET setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef4 ORG COUNTER # RESET setting. R
setSrcRef ObjectReference SP COUNTER # RESET setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef5 ORG COUNTER # FREEZE/RESET setting. R
setSrcRef ObjectReference SP COUNTER # FREEZE/RESET
setting
reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
InRef6 ORG COUNTER # FREEZE/COUNT setting. R
setSrcRef ObjectReference SP COUNTER # FREEZE/COUNT
setting
reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
BlkRef1 ORG COUNTER # BLOCK setting. R
setSrcRef ObjectReference SP COUNTER # BLOCK setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
LNName: DigElGAPC# LDevice inst: Gen UR element: Digital Element #
data obj. data attribute Type FC UR Name Description R/W/C
Str ACD Dig Element # PKP operand, which
indicates Op will operate when delay
expires.
R
general BOOLEAN ST Dig Element #(DE#) PKP R
dirGeneral ENUMERATED ST 0, the code for unknown R
Op ACT Dig Element # OP operand, which
becomes On when the input is On, and
the element is not blocked
R
general BOOLEAN ST Dig Element #(DE#) OP R
Dpo SPS Dig Element # DPO operand, which
indicates the element will drop out (Reset)
when delay expires.
R
stVal BOOLEAN ST Dig Element #(DE#) DPO R
InRef1 ORG DIG ELEM #INPUT setting. R
setSrcRef ObjectReference SP DIG ELEM #INPUT setting reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
BlkRef1 ORG DIG ELEM # BLOCK setting. R
setSrcRef ObjectReference SP DIG ELEM # BLOCK. reference to the data attribute to input R/C
setSrcCB ObjectReference SP source GoCB of input if via GOOSE R/C
LNName: DigCntFCNT# LDevice inst: Gen UR element: Digital Counters #
data obj. data attribute Type FC UR Name Description R/W/C
