5.2 Power Supply Requirements
The system must receive its power supply via a dedicated feeder run from the nearest Main
Distribution Panel (MDP).
The system is designed to operate on a three-phase plus neutral, five-wire Wye power source
(preferably a solidly grounded Wye source). The neutral wire is used in the NM sub-system only
and does not need to be routed to the CT PDU (i.e. five-wire connection).
NOTE
According to local regulations, a primary power disconnect device must be provided on the power line supplying the
CT PDU, see Power Input Distribution Box (PIDB) with MDP (A1),p.5-14.
Table 5-4: Power Supply Requirements
Characteristics Comments
Line voltage
specifications
380 to 480 VAC The difference between the highest line-to-line voltage and lowest line-to-
line voltage must not exceed 2% of the lowest line-to-line voltage. The
power input is a three phase + neutral + ground.
Line frequency
specifications
50-60 Hz ± 3 Hz
Measured kVa load
characteristics
D670/OPT 75 kVA
D670/BSE 90 kVA
Maximum power
demand
D670/OPT 75 kVA
D670/BSE 90 kVA
@ 0.85 PF, at a selected
technique of rotation 3 RPM,
L shape with LEHR collimator
Average (continuous)
power demand
20 kVA
at maximum duty cycle
