GE Druck DPI 880 - Electrical connectors (A2); Temperature ranges (RTD)

[EN] English - 19
K405 Issue 3
Specification - Temperature ranges (TC)
Specification - mV (TC) range
Thermocouple type Standard Range °F Range °C Accuracy °F * Accuracy °C *
K IEC 584 -454 to -328 -270 to -200 3.6 2.0
K IEC 584 -328 to 2 502 -200 to 1 372 1.1 0.6
J IEC 584 -346 to 2 192 -210 to 1 200 0.9 0.5
T IEC 584 -454 to -292 -270 to -180 2.5 1.4
T IEC 584 -292 to -94 -180 to -70 0.9 0.5
T IEC 584 -94 to 752 -70 to 400 0.6 0.3
B IEC 584 32 to 932 0 to 500 7.2 4.0
B IEC 584 932 to 2 192 500 to 1 200 3.6 2.0
B IEC 584 2 192 to 3 308 1 200 to 1 820 1.8 1.0
R IEC 584 -58 to 32 -50 to 0 5.4 3.0
R IEC 584 32 to 572 0 to 300 3.6 2.0
R IEC 584 572 to 3 214 300 to 1 768 1.8 1.0
S IEC 584 -58 to 32 -50 to 0 4.5 2.5
S IEC 584 32 to 212 0 to 100 3.4 1.9
S IEC 584 212 to 3 214 100 to 1 768 2.5 1.4
E IEC 584 -454 to -238 -270 to -150 1.6 0.9
E IEC 584 -238 to 1 832 -150 to 1 000 0.7 0.4
N IEC 584 -454 to -4 -270 to -20 1.8 1.0
N IEC 584 -4 to 2 372 -20 to 1 300 1.1 0.6
L DIN 43710 -328 to 1 652 -200 to 900 0.6 0.3
U DIN 43710 -328 to 212 -200 to 100 0.9 0.5
U DIN 43710 212 to 1 112 100 to 600 0.6 0.3
C 32 to 2 732 0 to 1 500 1.8 1.0
C 2 732 to 3 632 1 500 to 2 000 2.5 1.4
C 3 632 to 4 199 2 000 to 2 315 3.4 1.9
D 32 to 3 092 0 to 1 700 1.8 1.0
D 3 092 to 3 992 1 700 to 2 200 2.9 1.6
D 3 992 to 4 514 2 200 to 2 490 6.5 3.6
*Cold Junction (CJ) error (Maximum):
Range 50° to 86°F (10 to 30°C) = 0.4°F (0.2°C)
Add 0.01° CJ error / ° ambient temperature change for ranges: 14 to 50°F, 86 to 122°F (-10 to 10°C, 30 to 50°C)
Range
(mV)
Impedance Accuracy
(Measure/Supply)
-10 to 75 < 0.2 Ω 0.02% of reading + 7 counts
