GE GXSF30H Owner's Manual And Installation Instructions

25
Parts catalog. ge.com
GENERAL ELECTRIC PARTS CATALOG
G
X
S
F
3
0
H
REF. NO. PART NO. PART DESCRIPTION (03)
0003 WS35X10001 O-RING SEAL KIT 1
0004 WS34X10015 DECAL, FACEPLATE 1
0005 WS07X10004 HOSE, DRAIN, 20 FT. 1
0007 WS14X10002 DISTRIBUTOR, TOP 1
0008 WS14X10001 DISTRIBUTOR, BOTTOM 1
0009 WS01X10002 RESIN, 1 CU. FT. 1
0010 WS32X10011 RESIN TANK, 9 X 40 1
0011 WS31X10022 COVER, TOP W/ LENS 1
0012 WS31X10023 FACEPLATE 1
0013 WS21X10049 CONTROL 1
0016 WS26X10013 TRANSFORMER WITH
POWER CORD 1
0017 WS31X10021 COVER, SALT HOLE,
WITH LABELS 1
0018 WS33X10001 VAPOR BARRIER 1
0019 WS33X10007 RIM 1
0020 WS31X10024 COVER, BRINEWELL W/ DECAL 1
0021 WS02X10009 NUT 1
0022 WS32X10017 BRINEWELL W/ DECAL 1
0023 WS02X10027 SCREW 1
0024 WS32X10016 TANK, BRINE, ROUND 1
0025 WS18X10003 CLAMP, HOSE 2
0026 WS22X10016 ADAPTER, HOSE 1
0027 WS22X10017 GROMMET 1
0028 WS35X10035 GROUND CLAMP KIT 1
0029 WS15X10035 BRINE VALVE ASM. 1
0030 WS35X10036 FLOAT, STEM & GUIDE 1
0031 WS03X10006 CLIP 1
0032 WS15X10006 VALVE BODY, BRINE 1
0033 WS03X10007 CLIP 1
0034 WS03X10008 SCREEN 1
0035 WS07X10002 TUBING ASM. 1
0036 WS07X10015 BRINE TUBE ASM. 1
0037 WS31X10018 BACK COVER, ELECTRONICS 1
0038 WS02X10029 SPACER 1
0039 WS02X10030 FACEPLATE SUPPORT 1
0055 WS28X10003 RETAINER CLAMP 2
0056 WS28X10004 CLAMP 2
0101 WS02X10012 SCREW 1
0102 WS02X10013 SPACER 1
0103 WS21X10003 SWITCH 1
0104 WS03X10009 PIN, EXPANSION 1
0105 WS02X10014 SCREW 5
0106 WS31X10006 COVER, VALVE 1
0107 WS03X10010 WAVE SPRING 1
0108 WS26X10002 ROTOR & DISC ASM. 1
0109 WS19X10004 CAP, VENTURI 1
0110 WS03X10011 SEAL, O-RING 1
NOTE: Codes in the State of Massachusetts require installation by a licensed
plumber and do not permit the use of the saddle valve. For installation, use
plumbing code 248-CMR of the Commonwealth of Massachusetts.
