GE GXSF30V Owner's Manual And Installation Instructions

32
REF. NO. PART NO. PART DESCRIPTION (01)
0002 WS31X10051 BACK COVER, ELECTRONICS 1
0003 WS35X10001 O-RING SEAL KIT 1
0004 WS34X10020 DECAL, FACEPLATE 1
0005 WS07X10004 HOSE, DRAIN, 20 FT. 1
0007 WS14X10002 DISTRIBUTOR, TOP 1
0008 WS14X10005 DISTRIBUTOR, BOTTOM 1
0009
WS01X10002 RESIN, 1 CU. FT. 1
0010 WS32X10030 TANK, RESIN,
9 X 35 1
0011 WS31X10052 COVER, TOP 1
0012 WS34X10021 FACEPLATE 1
0013 WS21X10053 CONTROL 1
0016 WS26X10013
EXTERNAL POWER SUPPLY WITH
POWER CORD 1
0017 WS31X10053 COVER, SALT HOLE, WITH LABEL 1
0019 WS33X10010 RIM 1
0020
WS31X10024 COVER, BRINEWELL 1
0022
WS34X10025 BRINEWELL 1
0023
WS02X10088 SCREW KIT, BRINE TANK 1
0024 WS32X10031 TANK, BRINE 1
0026
WS22X10063 OVERFlOW ADAPTER KIT 1
0029 WS15X10077 BRINE VALVE ASM. 1
0030 WS35X10063 FlOAT, STEM & GUIDE 1
0056
WS28X10078 TANK NECK CLAMP KIT 1
0103 WS21X10003 SWITCH 1
0105 WS02X10014 SCREW
, #10 - 14 x 2” 5
0106 WS31X20060
COVER, VALVE 1
0107 WS03X10010
WASHER WAVE 1
0108 WS26X10002 ROTOR & DISC ASM. 1
0109
WS19X10010 CAP 1
0110 WS03X10011 SEAL, O-RING
1.125 X 1.37 1
0111 WS19X10005 SUPPORT SCREEN 1
0112 WS03X10013 SCREEN 1
0113
WS22X10036 FlOW PLUG, .15 GPM 1
0114
WS08X10008 GASKET, NOZZLE/VENT 1
0115
WS03X10073 SCREEN CONE 1
0116 WS22X10021 PLUG, FILL FlOW, .30 GPM 1
0117 WS03X10017
NUT FERRULE 1
0118 WS15X10034 NOZZLE/VENTURI BODY 1
0119 WS03X10018 RETAINER 1
 :6; 6($/25,1*Ǝ;Ǝ 
0121 WS15X10010 BODY, VALVE 1
0122 WS03X10020 SPRING 1
0123 WS22X10022 PLUG, DRAIN SEAL 1
0124
WS15X10046 NOZZLE/VENTURI ASM. 1
0130 WS35X10005
SEAL KIT 1
0132
WS22X10064 DRAIN HOSE ADAPTER KIT 1
0136/140 WS26X21822 MOTOR, CAM & GEAR KIT, 3/4" 1
0138 WS26X20061
MOTOR MOUNT 1
0141 WS02X20063 6&5(:[Ǝ 
0143 WS60X10013
ADAPTER—NPT THREADED—STD VALVE 2
0145 WS60X10004 CLIP 4
0146 WS28X10017
HARNESS WIRE, SENSOR ASSY 1
0147 WS19X10006 TURBINE & SUPPORT ASM.* 1
0151 WS15X21823 BYPASS VALVE ASM.* 1
0152 WS03X10025 SEAL, O-RING 4
0998
WS35X10064 INSTALLATION KIT 1
0999 49-50282-8 OWNER’S MANUAL 1
* Includes 2 each of REF. NO. 152 (O-RING)
Parts List
GXSF30V
