GE GXSH40V User Manual

34
REF. NO. GE PART NO. PART DESCRIPTION (00) (00)
0111 WS19X10005 SUPPORT SCREEN 1 1
0112 WS03X10013 SCREEN 1 1
0113 WS22X10036 FLOW PLUG, .15 GPM
1 1
0114
WS08X10008 GASKET, NOZZLE/VENT 1 1
0115
WS03X10073 CONE SCREEN 1 1
0116 WS22X10021 PLUG, FILL FLOW .30 GPM 1 1
0117 WS03X10017
NUT FERRULE 1 1
0118 WS15X10034 NOZZLE/VENTURI BODY 1 1
0119 WS03X10018 RETAINER 1 1
 :6; 6($/25,1*Ǝ;Ǝ  
0121 WS15X10025 BODY, VALVE 1 1
0122 WS03X10020 SPRING 1 1
0123
WS22X10029 PLUG, DRAIN SEAL 1 1
0124
WS15X10046 NOZZLE/VENTURI ASM. 1 1
0125 WS03X10043 WAVE SPRING BEARING 1 1
0130 WS35X10020
SEAL KIT 1 1
0132
WS22X10065 DRAIN HOSE ADAPTER KIT 1 1
0136/140 WS26X21821 MOTOR, CAM & GEAR KIT, 1" 1 1
0137 WS26X10009 BEARING 1 1
0138 WS26X10023
PLATE, MOTOR 1 1
 :6; 6&5(:;Ǝ  
 :6; 6&5(:;Ǝ  
 :6; $'$37(5±1377+5($'±Ǝ9$/9(  
0145 WS60X10008 CLIP 4 4
0146 WS28X10018
HARNESS WIRE, SENSOR ASSY 1 1
0148
WS26X10030 TURBINE & SUPPORT ASSEMBLY* 1 1
0151
WS15X10078 BYPASS ASM. 1 1
0152 WS03X10072 SEAL, O-RING 4 4
0998
WS35X10065 INSTALLATION KIT 1 1
0999 49-50283-8 OWNER’S MANUAL 1 1
G
X
S
H
4
0
V
G
X
S
H
4
5
V
* Includes 2 each of REF. NO. 145 (CLIP) & REF. NO. 152 (O-RING)
Exploded View/Parts List

GE GXSH40V Specifications

General

Brand	GE
Model	GXSH40V
Category	Water Dispenser
Language	English
