GE HEALTHCARE OPTIMA XR200AMX/XR220AMX
D
IRECTION 5336113-1EN, REVISION 10 INSTALLATION MANUAL
Chapter 5 Calibration Page 115
6. Record the results in the table below.
Table 5-1 PACS image test results
In addition to the test results above, use Table 5-2 as a guideline to determine if a PACS should be
configured as Burn-on-Send. This table considers only whether a PACS supports VOI-LUT
Table 5-2 PACS support of VOI-LUT
Example Test 1 Test 2 Test 3 Test 4 Test 5 Test 6 Test 7
Distinct dark
bands
3
1 0
2 0
3 0
4 2
5 3
6 4
7 5
8 4
9 4
10 3
11 3
12 0
Distinct bright
bands
6
No-Burn Burn-on-Send
GE Centricity RA1000 v1.0, v2.0, v2.1 GE Pathspeed v7.12, 8.0
GE Centricity RA600 v6.1, 7.0 GE AW v3.1, 4.0
GE Radworks v5.1 Kodak DirectView v4.3
GE Pathspeed v8.1 or later Kodak DirectView v5.1, 5.2
McKesson HRS v3.3, 3.3.2 Kodak Directview(CEMAX ICON), v4.3
Fuji Synapse v3.0, 3.1 Merge eFilm, v2.0
Agfa IMPAX v4.5, 5.2 Stentor iSite v3.0, v3.3.1
Philips Siemens Magic View 300
RealTime iPACS Viewer v5.0 VA Vista
- Picker
- Neusoft v3.0
- Thinking Systems
