3.4.4 Boom Mounted for Monitor Suspension
The purchaser/customer should prepare a Unistrut/ Halfen or equivalent ceiling structure. The
distance between center lines of the two longitudinal rails shall be 660.4 mm (26").
One type of boom mounted is supplied as counterpoised monitor suspension not adjusted on
site as follows:
- for 2 x 21” (53 cm) EIZO GmbH (formerly Siemens) flat panel 21” (Hi–bright) and additional
AW NEC monitor.
3.4.5 Cable Support for Monitor Cables
A cable support (cable drape) is provided with an Innova System.
The cable support kit contains:
•
1 B2054 EK (Drape with 3 M Bridge, on suspensions for X-Ray tubes and monitors,
contains 8 FT 6 inch track, three carriers, and mounting hardware)
•
1 B2055 ED (stationary rail parts)
NOTE: In Americas the Cable Support Kit must be provided locally by the Customer (e.g.
CPGE55 from Unistrut).
Innova
TM
IGS 520, Innova
TM
IGS 530, Innova
TM
IGS 540 Pre-Installation Manual
Direction 5499972-1-1EN, Revision 2
162 3 Room Structural Requirements
