2 Room Layouts
2.1 Room Dimension Requirements
WARNING
LOCATION IN TECHNICAL ROOM FOR ELECTRICAL CABINETS IS
MANDATORY.
THE ELECTRONIC CABINETS (C1, C2, OPTIONAL LD CABINET, COOLIX
4100 CHILLER, DETECTOR CHILLER AND FLUORO UPS WHEN
INSTALLED ) INCLUDE FANS THAT ARE CREATING AIR–CIRCULATION OF
PULSED–AIR. WHEN THIS PULSED AIR IS IN AN ENVIRONMENT THAT MAY
CONTAIN AIRBORNE PATHOGENS LIKE AN EXAM ROOM/CONTROL
ROOM, THERE IS A RISK OF TRANSMISSION OF THESE AIRBORNE
PATHOGENS FROM PATIENTS TO OTHER PATIENTS OR CLINICAL
PERSONNEL (NOSOCOMIAL DISEASES).
TO REDUCE THIS RISK, THE ELECTRONIC CABINETS MUST BE
INSTALLED IN A ROOM SEPARATED FROM EXAM ROOM/CONTROL ROOM,
I.E., TECHNICAL ROOM.
For exam and control rooms, several configurations are recommended.
NOTE:
Motion controls installed in remote location from the table shall be installed at a
location where all the positioner axis are visible by the operator.
In case the system has a tilting table, the remote motion controls shall not be installed
on the longitudinal axis of the Table (to avoid any operator visual dead angle due to
tilted table top hiding the patient).
Refer to Patient Room Layout and Control Room Layout to see recommended exam / control
rooms layouts.
Table 2-2: Exam Room dimensions
Length Width Ceiling Height
Recommended: 32 ft 0 in (9.75m) 20 ft 0 in ( 6.00 m) 10 ft 0 in (3.05 m)
Minimum:
For minimum exam room lengths, see different table configu‐
rations Table 2-3, Table 2-4, Table 2-5, Table 2-6 and Illus‐
tration 2-52
14 ft 5 in (4.40 m) 9 ft 0 in (2.74 m)
For the tables below, refer to Illustration 2-52
Note: For Head Extender Dimensional drawing, refer to Dimension Drawings
Table 2-3: Omega IV Table
Configuration
Minimum Room length in mm (inches)
without Head Extender (see note
above)
with Head Extender (see note above)
Cardio 1395 mm (54.9 in)
5470 (215.3) 5470 (215.3)
Innova
TM
IGS 520, Innova
TM
IGS 530, Innova
TM
IGS 540 Pre-Installation Manual
Direction 5499972-1-1EN, Revision 2
108 2 Room Layouts
