12
SURFACE CONTROLS
(continued)
Dual Surface Unit Switch
The left rear surface unit
has two cooking sizes to
select from so you can
match the size of the unit
to the size of the
cookware you are using.
To use the large (9-inch) surface unit,
push in the top portion of the COIL
SIZE switch next to the control knob.
Push in and turn the control knob to the
desired setting.
To use the small (6-inch) surface unit,
push in the bottom portion of the COIL
SIZE switch. Push in and turn the
control knob to the desired setting.
COIL
SIZE
Hot Surface Indicator Light
A HOT SURFACE light will glow brightly when any
radiant element is turned on, and will remain lit after
the unit is turned off until the cooktop is cool enough
to touch. Each element has its own HOT SURFACE
indicator light.
• It comes on instantly when the unit is turned on.
• It stays on even after the unit is turned off.
• It glows brightly until the cooktop is cool enough
to touch.
A HOT SURFACE light will glow brightly when
any radiant element is turned on.
ON OFF
TIME CONTROLS
COOKING
TIME
START
TIME
CLOCK
KITCHEN
TIMER
START
BROIL
HI/LO
CLEAR
OFF
OVEN
BAKE
SELF
CLEAN
CAUTION: When the surface controls are
turned off, the HOT SURFACE indicator light
will remain lit until the cooktop surface has
cooled to approximately 150°F. The glass ceramic
surface will retain heat after the indicator light
goes out. Use caution until the cooktop surface
has had time to cool.
