31-7000173 Rev. 0 23
Installation Instructions
Attach the oven to the top cabinet by inserting
2 self-aligning screws through outer top cabinet
holes. Turn two full turns on each screw. Be
sure to keep power cord tight. Be careful not
to pinch the cord, especially when mounting
flush to bottom of cabinet.
5
Cabinet Front
Cabinet Bottom Shelf
4
Tighten the two screws to the top of the oven
completely. (While tightening screws, hold
the oven in place against the wall and the top
cabinet.)
Filler Block
Oven Top
Equivalent
to Depth
of Cabinet
Recess
Install grease filters. See the Owner’s Manual
packed with the oven.
Self-Aligning Screw
3
