GE LOGIQ V2 User Guide

Overview
LOGIQ V2/LOGIQ V1 – User Guide 1-19
Direction 5610736-100 Rev. 9
Battery Installation
To install the battery to the bottom cover of the system:
1. Shut down the system and disconnect the AC/DC power
cord.
2. Put the battery into the battery box through the opening
place.
Figure 1-13. Place the battery on the bottom cover
3. Push the battery completely into the box until the battery is
locked and the battery lock is in the lock position.
Figure 1-14. Lock the battery
