GEK-106237P MIFII Digital Feeder Relay 2-29
2 PRODUCT DESCRIPTION 2.16 TECHNICAL SPECIFICATIONS
2
IEC 60255-22-4 Electrical Fast Transient Immunity Test Level 3 (±2 kV except for communications
terminals RS-485 and RS-232 where the
level was ±1 kV) with a perfomance criteria
A.
IEC 60255-22-5 / EN 61000-6-2 (2001) Surge Immunity Test Level 3 (±2kV CM, ±1kV DM)
IEC 60255-21-6 / EN 61000-6-2 (2001) Injected RF Signals Immunity Test Level 3 (10 V/m), 0.15 – 80 MHz.
IIEC 60255-11 / EN 61000-6-2 (2001) Voltage Dips and Interruptions Immunity
Tests
Duration and Voltage described in the
related report.
IEC 60255-22-1 (1988) 1 MHz Burst Disturbance Test Level 3 (±2.5 kV in common mode and ± 1
kV in differential mode) in the I/O terminals
specified in paragraph 4.2 of the
corresponding report.
IEC 61000-4-8 (1993) / IEC 61000-4-8
(1993)
50 Hz Magnetic Fields Immunity Test Level 5 (100 A/m for continuous applications
and 1000 A/m for transient applications) with
a performance criteria A.
IEC 60255-5 (1977) Measurement of Insulation Resistance In the paragraph relating to insulation
resistance for all groups defined in
paragraph 4 of the report.
IEC 60255-5 (1977) Impulse Voltage Test In the paragraph relating to impulse voltage
test for ±5 kV applicatios in common mode
and ± 1 kV in differential mode (class III) for
all the groups defined in paragraph 4 of the
correspond report.
IEC 60255-5 (1977) Dielectric Test In the paragraph relating to dielectric test for
2 kV, 50 Hz applications for all the groups
defined in paragraph 4 of the correspond
report.
