GEK-113000T F650 Digital Bay Controller 2-5
2 PRODUCT DESCRIPTION 2.3 ORDERING CODE
2
SPECIAL MODELS: MOD001: 6A output contacts instead of 16A.
Notes:
(1) The digit selected for option G must be equal or higher than the digit selected for option F for models including boards 4 and 5.
F1G5 is a valid selection and F5G1 is and invalid selection.
(2) Display options with language selection:
Graphic display: available for English, French, Spanish and Chinese languages. For chinese only IEC symbols option is
available (N in ordering code).
Basic display: available for all languages
For those applications requiring a high number of inputs and outputs, F650 units can be connected to a CIO module
(Remote CAN Bus I/O module) for using up to 2 additional boards.
F650 units allow monitoring and configuring these I/O boards as if they were internal boards, located on slots F and G. In
this case, slots are labeled as H y J.
The required information to completely define a CIO Module is shown on Table 2–2:.
Table 2–2: ORDERING CODE FOR CIO MODULE
(1) The digit selected for option J must be equal or higher than the digit selected for option H for models including boards 4 and 5.
CIOH1J5**: is a valid selection CIOH5J1**: is an invalid selection
CIO H - J - - DESCRIPTION
I/O BOARD IN SLOT H
1 16 Digital inputs + 8 outputs
2 8 Digital Inputs + 8 Outputs + 2 trip/close circuit supervision circuits
4 32 Digital Inputs
5 16 Digital Inputs + 8 Analog Inputs
I/O BOARD IN SLOT J
0 None
1 16 Digital inputs + 8 outputs
4 32 Digital Inputs (See Note 1)
5 16 Digital Inputs + 8 Analog Inputs (See Note 1)
AUXILIARY VOLTAGE
LO 24-48 Vdc (range 19.2 – 57.6)
HI 110-250 Vdc (range 88 – 300)
120-230 Vac (range 96 – 250)
ENVIRONMENTAL PROTECTION
H Harsh (Chemical) Environment Conformal Coating
