III. SERVICE GUIDE
3.1 REPLACEMENT OF DOOR
3.1.1 Remove the top hinge cover. Twist
and remove carefully not to hurt the
cover and cabinet with driver.
3.1.2 Remove the screw and top hinge
assy.
3.1.3 Remove the F door assy slightly and
remove it.
3.1.4 Remove the center hingr and remove
the R door assy.
3.1.5 Remove the door liner.
top hinge cover
top hinge
screw
center hinge
fix screw
door liner
remove screw with driverdoor packing
