DIRECTION 5854713-100, REVISION 2
VENUE FIT™ SERVICE MANUAL
Chapter 5 - Components and Function (Theory) 5-13
PRELIMINARY
Section 5-8
System Power Distribution
5-8-1 Introduction
The AC/DC adapter is the main Power Supply for the Venue Fit™System. It provides the DC voltage
required to power the system in all its operational modes, while providing power to charge its two
internal Li-Ion batteries. The AC/DC adapter also acts as the isolation barrier between the AC mains
and the System.
