7-12 VersaMax Modules, Power Supplies and Carriers User's Manual GFK-1504N
7
IC200MDL144
Input Module, 240 V AC Isolated 4 Points
Module Specifications
Module Characteristics
Points
4 Isolated Inputs
Module ID
FFFF8802
Isolation:
User input to logic (optical)
and frame ground
Group to group
Point to point
500 V AC continuous; 2000 V AC for 1 minute
None
500 V AC continuous; 2000 V AC for 1 minute
Carrier Requirement
Requires Box-Style, Barrier-Style or Spring-Style Carrier,
revision B or later. Cannot be used with Connector-Style
Carrier.
LED indicators One LED per point shows individual point ON/OFF status
OK LED indicates backplane power is present
Backplane current
consumption
5 V output: 30 mA maximum
External power supply
None
Thermal derating
None
Compatibility
Cimplicity
ME
VersaPro
Control
90
CPU
001
CPU
002
CPU
005
CPU
E05
DBI
001
EBI
001
GBI
001
PBI
001
HW,FW vers.
FW release
2.11 1.5 2.4
AA
1.0
AA
1.5
AA
2.1
AA
2.1
AA
1.1
AA
1.0
AA
1.0
AA
1.0
Input Characteristics
Input voltage
0 to 264 V AC (47 to 63Hz), 240 V AC nominal
On state voltage
Off state voltage
155 to 264 V AC
0 to 40 V AC
On state current
Off state current
7mA minimum
1.5mA maximum
On response time
Off response time
1 cycle maximum
2 cycles maximum
Input impedance
38.5 kΩ (reactive) at 60Hz, typical
46.3 kΩ (reactive) at 50Hz, typical
