GE VersaMax IC200ERM002 - IC200 ALG431 Analog Mixed Module, 12 Bit 0 to 10 VDC Input 4 Channels and Output 2 Channels

GFK-1504N Chapter 12 Analog Mixed I/O Modules 12-11
12
IC200ALG431
Analog Mixed Module, 12 Bit 0 to 10 V DC Input 4 Channels and Output 2 Channels
Module Specifications
Module Characteristics
Channels
4 single-ended inputs, one group,
2 single-ended outputs, one group
Module ID
FFFF9024
Isolation:
User input to logic (optical) and to
frame ground
Group to group
Channel to channel
250VAC continuous; 1500VAC for 1 minute
Not applicable
None
LED indicators
FLD PWR LED indicates field power is present
OK LED indicates backplane power is present
Backplane current consumption
5V output: 60mA maximum
Thermal derating
None
Configuration parameters
Output default
Diagnostics
Loss of User Side Power
Compatibility
PME programming
software
CPU
001
CPU
002
CPU
005
CPU
E05
DBI
001
EBI
001
GBI
001
PBI
001
HW, FW vers.
FW release
All
AA
1.0
AA
1.5
AA
2.1
AA
2.1
AA
1.1
AA
1.0
AA
1.0
AA
1.0
External Power Supply
Recommended range
+18 to +30 V DC (including ripple)
Current consumption at recommended range
160mA max (including load current)
12V operation range
9.6 to 15 V DC , 12 V DC nominal (including ripple)
Current consumption at 12V range
175mA max.(including load current)
Input Characteristics
Input voltage:
0 to 10V
Input Impedance
120kΩ minimum
Accuracy at 25 °C*
Accuracy at 0 to 60 °C
± 0.3% typical of full scale, ± 0.5% maximum of full scale
± 1% maximum of full scale
Resolution:
2.5mV = 8 counts
Filter response
5.0ms
Update rate per module
0.4ms
Common mode voltage
0 V
Channel-to-channel crosstalk rejection
30dB minimum
Output Characteristics
Output voltage
0 to 10.24 V DC
Load characteristics
Resistive: 5000 Ω minimum
Capacitive: 1.0µF maximum
Accuracy at 25 °C
†
Accuracy at 0 to 60 °C
± 0.3% typical of full scale, ± 0.5% maximum of full scale
± 1% maximum of full scale
Resolution
2.5mV = 8 counts
Update rate per module
0.3ms maximum
Channel-to-channel crosstalk rejection
70dB minimum
Output default
Hold Last State (configurable), 0 (default)
†
In the presence of severe RF interference, (IEC 1000-4-3, 10V/m), accuracy
may be degraded to ± 1%.
