Chapter 7 - Diagnostics/Troubleshooting 7-23
NOTE: For complete shortcut list refer to Section 7-2-2 "Shortcuts List" on page 7-6.
Press the shortcut ALT
+ S on the alphanumeric keyboard, to display the Console Emulator.
NOTE: For description of keys and their functions refer to Section 5-6-2 "OPIO layout" on page 5-30.
NOTE: To regain free sight to the monitor image, the virtual Voluson® P8 / Voluson® P6 console disappears
as soon as you select a button. It is simply hidden in the background. Press the shortcut ALT
+ S twice
to show it again.
Figure 7-27 Voluson® P8 / Voluson® P6 Console Emulator
