GE HEALTHCARERAFT VOLUSON® P8 / VOLUSON® P6

DIRECTION 5459672-100, R

EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL

8-10 Section 8-3 - System Software - Installation/Upgrade Procedure

which Software/Hardware version is installed in the unit.

Figure 8-8 Version check (System Setup - Administration - SYSTEM INFO page)

currently installed Ultrasound

Application Software version

Voluson P8

Date of Factory Settings
