www.geeetech.com
Page 28
ShenZhen GETECH CO.,LTD
Videos
3 Assembling the carriage
Name
Part #
Qty.
Carriage mount
#A12
3
Belt mount
#M2
3
Endstop trigger mount
#M3
3
Diagonal Rod joint
#M4
6
PCS10UU
Linear Bearing
#37
6
M3x8mm Screw
#19
6
M3x12mm Screw
#20
12
M5x16mm Screw
#28
12
M5x20mm Screw
#29
12
M3x40mm Screw
#24
3
