Geeetech Rostock 301 Building Instruction

www.geeetech.com
Page 40
ShenZhen GETECH CO.,LTD
6 Mount the carriage and the top plate
Name
Part #
Qty.
M4 x 8 Screw
#25
6
M8 Washers
#7
6
M4 washer
#6
6
Step 1. Slide the carriages down the smooth rods (#1) pairing one carriage with
each set of 2 smooth rods (#1). You should now have the beginnings of
three towers (X, Y and Z).
