www.geeetech.com
Page 44
ShenZhen GETECH CO.,LTD
7 Mount the Belt
7.1 Assemble the drive wheel
Part name
Part #
Qty.
Drive wheel holder
#35
3
Drive wheel
#34
3
R84zz Ball Bearing
#33
6
M3 x16mm screw
#21
3
M4 x 20mm screw
#27
3
M4 washer
#6
3
M4 lock nut
#11
3
wing nut
#12
3
