In an Emergency
159
IF14 10A Backup Light Fuse
IF15 10A Air Bag IG2 Fuse
IF16 10A Rear Defroster Fuse
IF17 10A Hazard Warning /Turn Signal Fuse
IF18 20A Door Lock Fuse
IF19 5A
Instrument Cluster/HAVC/BCM Bat-
tery/ Room Light/Sunroof Fuse
IF20 10A Brake Light Fuse
IF21 10A
Diagnostic Interface/ Keyless Start
System Fuse
IF22 10A Headlight Fuse
IF23 10A
Position Light/Tail Light/Backlight/
License Plate Light
Fuse
IF24 10A Horn
IF25 10A
Instrument Cluster IG1/Power Sun-
roofIG1/HAVC IG1/ Sunlight Sensor
Fuse
IF26 10A BCM IG1 Fuse
IF27 20A Front Wiper Fuse
IF28 10A Rear Wiper Fuse Hatchback
IF30 15A Windshield Defroster Export
Position Amperage Name Remark
To Next Page
