GEM Owner’s Manual - Page 54
Operation and Maintenance
Flooded Battery Fill Well
1. Bottom of Fill Well
2. Vented Cap
The detailed view in Figure 20 shows the internal features of a fi ll well.
Each battery contains two vented caps and six fi ll wells. Figure 20
shows one vented cap removed to show the three fi ll wells.
*See Page 57 for fi lling instructions
NOTE:
Gel batteries do not have fi ll wells, as they are maintenance
free.
Figure 20 - Fill Wells of fl ooded battery
2
Top of Battery
Battery Plates
1
