GEM Owner’s Manual - Page 66
Operation and Maintenance
Figure 26 - Fuse Access Panel
FUSE ACCESS PANEL/FUSE BLOCK
The fuse block (Figure 25) is located inside the fuse access panel
(Figure 26), which is on the lower dash. The ignition key opens
the fuse access panel. To open, turn the key counterclockwise one
quarter turn.
Figure 25 - Fuse Block
