Gemini FX-7000 Service Manual

CABINET PARTS AND PACKING
ITEM PART NUMBER Q't
y
ENGLISH NAME
1 012-073 1 PANEL CONTROL
3 034-153 1 PANEL, REAR
4 032-171 1 COVER, BOTTOM
5 022-392 1 HOLDER, FADER
7
8 023-674 4 KNOB SWING
9 002-589 1 PUSH KNOB -WHITE
10 002-531 2 KNOB PUSH (SMALL)
11 002-532 1 KNOB PUSH BUSHING (SMALL)
12 002-585 5 KNOB PUSH
15 002-724 4 KNOB SLIDE (BIG)
16
17 003-171 11 KNOB ROTARY (A)
18 003-172 5 KNOB ROTARY (B)
19 003-173 3 KNOB ROTARY (C)
20 003-174 1 KNOB ROTARY (D)
21 003-175 3 KNOB ROTARY (E)
22
25
42 255-291 1 GIFT BOX
43 257-036 1 OWNER'S MANUAL
44 153-237 1 POLYFORM
45 END CABINET PARTS
10
11 074-145 5 INTEGRATED CIRCUIT NJM2068LD
12 074-104 1 INTEGRATED CIRCUIT NJM4558LD (M5218AL,BA4558N)
13 074-113 1 INTEGRATED CIRCUIT NJM4556L
14 074-166 1 INTEGRATED CIRCUIT LB1482M
15 074-107 1 INTEGRATED CIRCUIT NJM7812FA
16 074-114 1 INTEGRATED CIRCUIT NJM7912FA
17 074-074 1 INTEGRATED CIRCUIT NJM7805FA
18 074-211 1 INTEGRATED CIRCUIT NJM79L08A
19 074-212 1 INTEGRATED CIRCUIT NJM78L08A
20 074-216 1 INTEGRATED CIRCUIT W78E58B-40
21 074-210 21 INTEGRATED CIRCUIT NJM2068MD
22 074-213 1 INTEGRATED CIRCUIT TB62706BF
23 074-214 1 INTEGRATED CIRCUIT TC4052BFN
24 074-215 6 INTEGRATED CIRCUIT TC4053BFN
25
26 074-207 1 INTEGRATED CIRCUIT AL1101
27 074-208 1 INTEGRATED CIRCUIT AL1201
28 074-209 1 INTEGRATED CIRCUIT AL3201
29
30 076-104 1 TRANSISTOR 2SA1048 (2SA1317)
31 076-095 6 TRANSISTOR 2SC2878
32 076-002 1 SILICON TRANSISTORS 2SC945 (Q)(P)
33 076-003 SILICON TRANSISTORS OR 2SC1815 (Y)(GR)
34
35 079-027 6 RECTIFIER DIODE 1N4002
36 079-003 33 SILICON DIODE 1N4148
37 079-021P 7
ZENER DIODE 1/2W 3V (
¢
¢
ª
ª
BZX79C3V0)

Gemini FX-7000 Specifications

General

Brand	Gemini
Model	FX-7000
Category	Music Mixer
Language	English
