GD-L115BT
GD-L115BT
22: Light Power ON/OFF button: Turns the light
system on or off.
23:
Light Mode: Changes the lighting modes for the
front mounted speaker lighting.
24:
Light Color: Cycles the color of the front mounted
speaker lighting.
1.Channel 1 volume : Adjusts the loudness of the source
connected to CH1
2.
BT Pair : Activates pairing mode to connect a phone,
tablet, or other external media source.
3. BT Link: Allows user to link another GD series
speaker via bluetooth to create a stereo pair.
4. Channel 2 volume : Adjusts the loudness of the source
connected to CH2
5. Clip LED: Indicates audio clipping.
6.
AUX input（TRS): Connect a digital media player,
etc. to this 1/8" stereo input.
7/12. Mic/Line input switch: Allows user to choose
the MIC or Line signal input.
8/13.
Mic/Line input: Connect a microphone or line
signal to this 1/4" TRS input
9/14:
Mic/Line input: Connect a microphone or line
signal to this XLR input
10:
Channel 3 volume : Adjusts the loudness of the
source connected to CH3
11:
AUX Input (RCA): Connect a CD player, mixer, or
other media source to this line level RCA input.
15:
Mater volume: Adjust the loudness of the whole
system.
16:
Bass EQ: Controls the bass(low) frequencies of
speaker at a range between -12dB to + 12dB.
17:
Treble EQ: Controls the treble(high) frequencies of
speaker at a range between -12dB to + 12dB.
18:
Mix Out: Use this XLR output to create a wired
connection to another powered speaker, etc.
19:
Power ON/OFF Switch: Turns unit on or off.
20:
Voltage Switch : Allows user to change the AC
voltage input.
21：
AC Power Input: Mains power supply(supplied
with speaker) plugs in here.
