INTRODUCTIONINTRODUCTION

INTRODUCTION

Congratulations on your purchase of a

Gemini Gemini

Gemini

PMXPMX

PMX

-250-250

-250

MixMix

Mix

erer

. This state-of-the-art mixer features the latest technological

advances and is backed by a three year warranty, excluding crossfader

and channel slides.

CACA

UTIONSUTIONS

UTIONS

1. All instructions should be read before using this equipment.

2. To reduce the risk of electrical shock, do not open the unit. THERE

ARE NO USER REPLACEABLE PARTS INSIDE. Please refer all

servicing needs to a Gemini-qualified service technician.

In the USA ~ if you experience problems with this unit

call Gemini Customer Service at: 1 (732) 738-9003.

Do not attempt to return this equipment to your dealer.

3. Do not expose this unit to direct sunlight or a heat source such as

a radiator or stove.

4. This unit should be cleaned only with a damp cloth. Avoid solvents

or other cleaning detergents.

5. When moving this equipment it should be placed in its original carton

and packaging. This will reduce the risk of damage during transit.

6. DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

7. DO NOT USE SPRAY CLEANERS OR LUBRICANTS ON CONTROLS,

SURFACES OR SWITCHES.

CONNECTIONSCONNECTIONS

CONNECTIONS

1. Ensure that the POWER (9) switch is in the OFF position prior to

making any connections. This unit comes with a 15 volt AC adaptor.

Plug the adaptor into the rear panel POWER JACK (1) before

plugging it into a proper power source.

2. MASTER OUTPUT (2) connects this unit to the main amplifier using

standard audio cables with RCA-type connectors.

3. Headphones may be plugged into the front panel-mounted

HEADPHONES (5) jack.

PHONO inputs accept

only

turntables with magnetic

cartridges. Additional units, such as CD players, utilize `

the LINE inputs and require the proper switch setting.

4. Attach a phono ground line to the GROUND THUMB SCREW (13).

NONO

TE:TE:

TE:

NotNot

Not

attac attac

attac

hing a grhing a gr

hing a gr

ound maound ma

ound ma

y cause a system y cause a system

y cause a system

“hum.“hum.

“hum.

””

”

OPERAOPERA

OPERA

TIONTION

TION

1. POWER ON: Once all equipment connections have been made,

press POWER (9) switch. Power is ON when POWER LED (8)

is illuminated.

2. CHANNEL 1: The PH-1/LN-1 (6) switch allows you to select

PHONO 1 or LINE 1. CHANNEL SLIDE (11) controls the input

level of this channel.

3. CHANNEL 2: The PH-2/LN-2 (7) switch allows you to select

PHONO 2 or LINE 2. CHANNEL SLIDE (12) controls the input

level of this channel.

4. CROSSFADER: The CROSSFADER (16) allows the mixing of

one source into another. The left side of the CROSSFADER

is Channel 1 while the right belongs to Channel 2.

Note: Do not apply pressure while using the Crossfader.

Lightly glide the crossfader back and forth. Pressing down

on the controls can bend contacts and cause a loss of sound.

5. CUE: Connecting a set of headphones to the HEADPHONES jack

allows you to monitor either Channel 1 or Channel 2. Select

Channel 1 by moving CUE SWITCH (14) to the left. Listen to

Channel 2 by moving CUE SWITCH to the right. Use CUE LEVEL

(15) to adjust headphone volume without affecting the speaker-

driven mix. Cue facilitates the seamless blending of one recorded

track into another.

6. DISPLAY: DISPLAY (10) indicates the MASTER output.

SPECIFICASPECIFICA

SPECIFICA

TIONSTIONS

TIONS

INPUTS:INPUTS:

INPUTS:

Phono...................................................................................3 mV, 47 kOhm

Line...................................................................................250 mV, 27 kOhm

OUTPUTS:OUTPUTS:

OUTPUTS:

Amp...................................................................................0 dB 1 V, 400 Ohm

Max......................................................................................18 V Peak to Peak

GENERAL:GENERAL:

GENERAL:

Frequency Response......................................................20Hz - 20 kHz +/- 2 dB

Distortion........................................................................................0.02%

S/N Ratio.............................................................................better than 80 dB

Headphone Impedance...........................................................................16 Ohm

Power Source......................................115V/15V AC 7.5W (or 230V/15V AC 7.5W)

Dimensions...................................................10" x 6.5" x 2" (254 x 165 x 51 mm)

Weight........................................................................................3 lbs. (1.3 kg)

Specifications and designs are subject to change without notice for the purpose of improvement.

CACA

UTIONUTION

UTION

ELECTRICAL HAZARD

DO NOT OPEN

Record and save the serial

number from the back of

your Gemini Mixer here for

future reference:

Purchase Date:

Model #: Gemini PMX-250 Mixer

Serial Number:
