TECHNICAL DATA ORALIX AC SYSTEM
Gendex Dental SystemsA-6
4. TECHNICAL DATA
4.1. MAINS SUPPLY
Mains voltage 230 VAC +/-10%, single phase (polarized) or double phase
it is reccomended to use a dedicated magneto/thermal circuit breaker (10
A max) and an earth leakage circuit breaker (leakage current of 30 mA)
Current absorption$0D[LPXP$6WDQGE\
Mains fuse F6.3A / 250V, fast blow 2
nd
fuse for double phase, with by-pass jumper
Frequency 50 Hz / 60 Hz ± 2 Hz
Line resistance 0.8 Ohm
4.2. TUBEHEAD
Peak tube potential (see section D-3.2.) 60.0 kVp +/- 8% (Nominal mains Voltage -10%)
65.0 kVp +/- 8% (Nominal mains Voltage)
68.5 kVp +/- 8% (Nominal mains Voltage+10%)
Tube current (see section D-3.3.) 6. mA +/- 10%Nominal mains Voltage -10%)
 mA +/- 10%Nominal mains Voltage)
. mA +/- 10%Nominal mains Voltage +10%)
Radiation output5 mGy/sec +/-30% at 20 cm from the focus
Tube rating chart (only 1 fixed working point) 65 kVp, .5 mA, 2.5 s
X-ray tube

800-000G
, grid controlled, single focusDQG
X-ray Tubehead Oil immersed, shielded
Minimum filtration permanently in the beam 2.0 mm Al equiv. @ 65 kVp (IEC 522/1976)
Beam quality half value layer (H.V.L.) better than 1.7 mm Al @ 65 kVp
Focal spot 0.7 mm (IEC 336/1982)
Duty cycle 1
Minimum wait time 3 sec
Radiation leakage less than 4 microGy/h (5 mR/h) @ 1 meter
Leakage Tecnique factors 0.1 mA @ 65 kVp
Anode angle 19.5° +/- 0.5 respect to the UHIHUHQFH axis
pXOVH
7DUJHWPDWHULDO7XQJVWHQ
