Generac 2700PSI High Pressure Washer
GENERAC
The Reliable Ones
8
ASSEMBLY
Clean area around gas cap. Remove cap
(Figure 5).
Add UNLEADED gasoline, slowly, to fuel tank.
Use a funnel to prevent spillage.
Install gas cap and wipe up any spilled gasoline.
Connect Hose and Water
Supply to Pump
WARNING! You must assemble wand and
attach all hoses before you start engine.
Starting engine without all hoses connected
and water supplied will damage pump.
Uncoil high pressure hose and attach the end of the
hose with the threaded end to the base of the spray
gun (Figure 6). Tighten by hand.
Attach other end of high pressure hose to the high
pressure outlet on the pump (Figure 7). Tighten by
hand.
Before you connect your garden hose to the water
inlet, inspect the water inlet screen (see Figure 8).
Clean the screen if it contains debris or have it
replaced if damaged. Do not run the pressure
washer if the water inlet screen is damaged.
Connect garden hose to water inlet. Tighten firmly
by hand (Figure 8).
Turn on the water (open valve completely).
Squeeze trigger on gun to purge pump system of
air and impurities. Squeeze until a steady stream
appears.
WARNING! Before starting the pressure
washer, be sure you are wearing adequate eye
protection.
Attach dual lance to spray gun. Tighten by hand.
Figure 6 Connect high pressure hose
to spray gun.
Figure 5 Add gasoline to fuel tank.
Gas Cap
Connect High Pressure
Hose Here
Figure 7 Connect high pressure hose to
pump.
Connect High
Pressure Hose
Here
Figure 8 Connect the garden hose to water
inlet and turn ON the water.
Check Screen
for Damage
and Connect
Garden Hose
Here
To Next Page
