Generac Portable Products 2700PSI High Pressure Washer
Item Part # Qty Description
1 100-92293P 1 Crankcase
2 101-92293P 1 Plug
3 102-92293P 1 O-Ring
4 103-92293P 1 Protector
5 104-B3169 3 Oil Seal
6 104-92293P 1 Plug
8 106-92293P 8 Washer
9 107-92293P 8 Screw
10 108-B3169 6 O-Ring
11 109-B3169 6 Valve Seat
12 110-B3169 6 Valve Plate
13 111-B3169 6 Spring
14 112-B3169 6 Valve Cage
15 108-92293P 6 O-Ring
16 114-B3169 6 Valve Cap
17 115-B3169 6 Valve Assy.
18 116-B3169 3 Head Ring
19 117-B3169 3 Packing
20 118-B3169 3 Packing Retainer
21 119-B3169 3 O-Ring
22 120-B3169 3 O-Ring
23 110-92293P 1 Sight Gauge
24 111-92293P 1 Needle Bearing
25 94504 1 Oil Dip Stick
26 112-92293P 3 Nut
27 113-92293P 3 Washer
28 150-92293P 3 Plunger
29 114-92293P 3 O-Ring
30 115-92293P 3 Back Up Ring
31 116-92293P 3 Flinger Washer
32 117-92293P 3 Conn. Rod Pin
33 118-92293P 1 Crankcase Cover
34 126-92293P 4 Screw
35 120-92293P 1 Cover O-Ring
36 134-B3169 3 Connecting Rod
37 122-92293P 3 Plunger Rod
49 136-B3169 4 Screw
50 137-B3169 4 Washer
51 138-B3169 1 Flange
52 126-92293P 4 Screw
53 106-92293P 4 Washer
54 128-92293P 1 Spacer
Item Part # Qty Description
55 129-92293P 1 O-Ring
56 130-92293P 1 Oil Seal
57 131-92293P 1 Snap Ring
58 132-92293P 1 Bearing
59 146-B3169 1 Crankshaft
60 134-92293P 1 Knob
61 148-B3169 1 Bolt
62 149-B3169 1 Nut
63 137-92293P 1 O-Ring
64 138-92293P 1 Pressure Regulator
65 152-B3169 1 Seal
66 140-92293P 1 Spring
67 154-B3169 1 Bushing
68 108-92293P 1 O-Ring
69 156-B3169 1 Stopper
70 157-B3169 1 Spring
71 158-B3169 3 O-Ring
72 159-B3169 1 Ball
73 160-B3169 2 Back Up Ring
74 161-B3169 2 O-Ring
75 162-B3169 1 Piston
76 163-B3169 1 Back Up Ring
77 164-B3169 1 Valve Guide
78 165-B3169 1 O-Ring
79 166-B3169 1 Back Up Ring
80 167-B3169 1 Valve
81 168-B3169 1 Screw
82 169-B3169 1 Valve Seal
83 170-B3169 1 O-Ring
84 100-B3169A 1 Nipple, 3/8 NPT
86 172-B3169 1 UI Manifold
87 173-B3169 1 Cap
88 104-92293P 1 Cap
89 161-B3169 1 O-Ring
90 142-92293P 1 Nozzle
91 177-B3169 1 O-Ring
92 178-B3169 1 Spring
93 179-B3169 1 Ball
94 114-92293P 1 O-Ring
95 197-B3169 1 Hose barb
96 112-92293P 1 O-Ring
97 199-B3169 1 Injector Housing
Kit Description
Part # Items included in kit # Assys in kit
Valve Kit 500-92294P 10, 11, 12, 13, 14, (17) 6
Oil Seal 500-92293P 5 3
ORing 192-B3169 20, 21, 22 3
ORing 506-92294P 83,89,91,92,93,94,95,96 
ORing 503-92293P 18, 19, 20, 21, 22 1
ORing 195-B3169 18, 19, 21, 22 3
ORing 505-92293P 67,68,69,70,71,72,73,74,75,76, 77,78,79,80,81,82 
