Grasp the recoil starter handle with your right hand
and pull slowly until you feel some resistance. Then
pull rapidly to start the engine.
Return the starter handle slowly. Do Not let rope
snap back against starter.
If the choke lever was placed in the Choke
position to start the engine, move it slowly to the
Run position as the engine warms up enough to
run smoothly.
If the engine fails to start, review instructions given
in the engine owners manual.
Engage the safety latch to the spray gun trigger
(Figure 11).
Attach the adjustable nozzle extension to the spray
gun. Tighten by hand (Figure 12).
How to Stop Your Pressure Washer
Move throttle lever on engine to Stop position.
Squeeze trigger on the spray gun to relieve
pressure in the hose.
NOTE: A small amount of water will squirt out when
you release the pressure.
How to Use the Adjustable Nozzle
You now should know how to START your pressure
washer and how to STOP it. The information in this
section will tell you how to adjust the spray pattern
and apply detergent or other cleaning chemicals.
DANGER! Never adjust spray pattern when
spraying. Never put hands in front of nozzle to
adjust spray pattern.
The adjustable nozzle affixed to the nozzle extension
permits you to adjust the spray pattern and the spray
pressure, as follows:
Slide the nozzle forward to adjust the spray to low
pressure mode (Figure 13). Slide the nozzle
backward to achieve high pressure.
Point the nozzle down towards a firm surface and
press the trigger to test the pattern (Figure 14).
Generac Portable Products 2,100 PSI High Pressure Washer
9
Safety Latch
Figure 11 Spray Gun with Safety Latch Engaged
Slide nozzle backward
for high pressure
mode.
Slide nozzle forward
for low pressure mode
and detergent
application.
Figure 13 - Adjusting Spray Pressure
Figure 14 Test the Spray Pattern
Figure 12 Connect Nozzle Extension to Spray Gun
