Generac 2000PSI High Pressure Washer
GENERAC
The Reliable OnesThe Reliable Ones
REPAIR PARTS  PUMP
Item Part # Qty Description
1 B3287 1 O-RING, 1.625" x 0.103
2 B2260 1 ADAPTER, Engine
3 96542 2 BEARING, Eng. Adptr. Roller
Thrust 4 x 4
4 B3329 1 CAM, Axial 6.0 Lift Assembly
6 B2261B 4 SCREW, Button Hd 5/16 - 24 x
3/4" Lg
7 B2217 4 O-RING, 0.239 ID x 0.070
8 94944 3 SHOE, Piston Pivot
9 99427 3 ASSEMBLY, Ceramic Piston &
Cap
10 96400 3 SPRING, Piston Return
11 99735 1 ASSEMBLY, Breather
12 93790 1 O RING, Crankcase 113.97 x
119.21 x 2.62
13 B2016 1 CRANKCASE ASSEMBLY
14 93668 3 SPACER, Pilot
15 40945 6 SCREW, SHC M6 x 1.0 x 20
mm Lg
16 93652 1 SPRING, Thermal Relief Actua-
tor
17 95416 1 PISTON, Thermal Relief Actua-
tor
18 93876 1 O RING, Thermal Relief 2.9 x
6.5 x 1.78
19 B2015 1 SPACER ASSEMBLY
20 A2069 1 GASKET, Head
21 97934 6 O - RING, Check Valve
22 B1449 6 CHECK VALVE, Inlet and Outlet
23 93644 1 ACTUATOR, Thermal Relief
24 96053 3 SEAL, High Pressure
25 96015 3 RING, Bearing
26 95380 1 SPRING, Chemical Injector
27 95379 1 BALL, 5.5 dia. Chemical Injector
28 A1575 1 BARB HOSE, Brass with Nylon
Insert
Item Part # Qty Description
29 B2151 1 VENTURI ASSEMBLY
30 89138 1 SPRING, Check Valve
31 B1879 1 SHUTTLE PISTON ASSEMBLY
32 A2503 1 SEAT, Trapped Line Pressure
33 A2015 1 BALL, Stainless Steel 9/32 Dia.
34 B2152 1 BALL SEAT ASSEMBLY
35 97840 3 O RING, Chk Valve Cap15.6 x
19.16 x 1.78
36 97841 3 CAP, Outlet Port
37 A2013 6 BOLT, Head M8 x 1.25 x 70mm
Lg
38 B2665 6 WASHER, Steel Special
39 B3148 1 HEAD ASSEMBLY
40 B3185 1 UNLOADER SPINDLE ASSEM-
BLY
41 A1716 1 SPRING, Unloader
42 B3117 1 HANDLE, Unloader
43 A2014 1 SET SCREW, M6 - 1.0 x 8mm
44 B2241 1 CAP, Plastic
Service Kits
45 B3519 0 CAM ASSEMBLY, 6.0 LIFT
46 B3507 0 HEAD ASSEMBLY
47 B3508 0 CRANKCASE ASSEMBLY
48 B3509 0 SPACER PLATE ASSEMBLY
49 B3480 0 COMPLETE HEAD ASSEMBLY
50 B3510 0 HIGH PRESSURE OUTLET
ASSEMBLY
51 B3513 0 CHECK VALVE ASSEMBLY, 6
pkg.
52 B3479 0 UNLOADER SPINDLE ASSEM-
BLY
53 B3478 0 PISTON/SHOE ASSEMBLY
54 B3514 0 O-RING/SEAL KIT
