General 10-110 User Manual

UNPACKING AND PREPARATION FOR SETUP & ASSEMBLY
UNPACKING
Carefully unpack and remove the unit and its components from its shipping container and check for missing or
damaged items as per the list of contents below.
Note: Please report any damaged or missing items to your GENERAL® INTERNATIONAL distributor immediately.
SAFETY
USE CAUTION AND WEAR GLOVES WHEN HAN-
DLING METAL PARTS SUCH AS THE BELT CLAMPS,
WHICH CAN CUT IF HANDLED CARELESSLY.
DO NOT OVEREXERT. ARRANGE TO HAVE HELP
NEARBY AND READY FOR UNPACKING AND
SET- UP.
THE SOUND LEVEL OF THIS MACHINE IS RATED AT
APPROXIMATELY 80 TO 90 DB DURING OPERA-
TION. MAKE SURE THAT ADEQUATE HEARING PRO-
TECTION IS USED AND THAT THE OVERALL SOUND
LEVEL WITHIN THE WORKING ENVIRONMENT IS
TAKEN INTO CONSIDERATION.
ADDITIONAL REQUIREMENTS FOR SETUP & ASSEMBLY
• Flat piece of wood (such as a ruler)
• Medium phillips screwdriver
• 10 & 12 mm open end wrench or adjustable wrench
• 1 extra person for help with lifting
LIST OF CONTENTS QTY
A- DRUM ........................................................................... 1
B- COLLECTOR BODY & MOTOR ASSEMBLY .................. 1
C- CONNECTOR ............................................................... 1
D- BASE PLATE ................................................................... 1
E- VERTICAL SUPPORT ROD ............................................. 1
F- FILTER BAG (10-110 ONLY) .......................................... 1
G- BAG HANGER (10-110 ONLY) ..................................... 1
H- COLLECTOR BAG ......................................................... 1
I- BELT CLAMP ................................................................. 2
LIST OF CONTENTS QTY
J- FOAM GASKET ............................................................. 1
K- RUBBER GASKET ........................................................... 2
L- HOSE INLET (“Y” FITTING)............................................. 1
M- CASTER ......................................................................... 4
N- HARDWARE BAG .......................................................... 1
WRENCH .................................................................................. 1
HEX. HEAD BOLT (5/16” X 1/2”) .......................................... 40
CROSS HEAD SCREW (3/16” X 3/8”) ..................................... 1
OPEN END WRENCH 10-12 MM ............................................. 1
O- CANISTER FILTER (10-110CF ONLY) ............................. 1
7
A
B
C
D
E
G
F
H
I
K
J
L
M
N
O
WITH 10-110CF
